Loren Fully Automatic Water Purifier

Loren Fully Automatic Water Purifier

Payment Type: T/T

Supply Ability: 15 sets Per month

    Contact Now
    Share:
    Product Attributes Supply Ability & Additional Information
    Product Attributes

    Model No.: LWP-30

    Brand: Loren

    Status: New

    Applicable Industry: Hotels, Farms, Food &Amp; Beverage Shops, Restaurant, Manufacturing Plant, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining

    Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

    Video Factory Inspection: Provided

    Mechanical Test Report: Provided

    Marketing Type: Ordinary Product

    Core Component Warranty Period: 1 Year

    Core Components: Pump, Pressure Vessel

    Place Of Origin: China

    Productivity: 10000l/Hour, 750l/Hour, 1000l/Hour, 20000l/Hour, 2000l/Hour, 3000l/Hour, 4000l/Hour, 5000l/Hour, 7500l/Hour, 50000l/Hour, 2500l/Hour

    No: Back-Flush Pump, Air Compressor

    5% Less: Water Consumption

    50% Small Area: Saving

    Outlet Water Quality: Stable and Excellent

    Impact-Tolerance Capacity: Strong Load

    Key Function: Removal Turbidity and TSS

    Esp. For: NTU less thank 3000mg/l

    Maintenance: Easy

    Service Life: Long


    Product Description

    Loren Fully Automatic Water Purifier

    Brief Introduction of Integrated Water Purification Equipment

    LWP Series Lake and Water Works Water Purifier is Widely Used In The Automatic Purification Of Surface Water Turbidity With Its Unique Structure & Scientific Use Of Hydraulics.

    Component

    Our Integrated Water Purifier Integrates Mixing, Reaction, Flocculation, Sedimentation, Filtration, Mud Discharge, Water Collection and Water Distribution To Meet The Requirements Of Automatic Operation.

    600 Integrated Purified Water System 7

    Combined Water Treatment System Feature

    -Special Fit for Such Lake Source with Low Temp. And Low Turbidity( NTU Below 3000mg/L)  as well as Seasonal Algae

    -Saves One-Time Investment & Daily Operating Costs Due To No Need Back-Flush Pump and Air Compressors

    -About 5% Less Water Consumption Saves Limited Water Resources

    -Only Do Water Quality Monitoring with No Operation Management thus to Reduce The Labor Working Intensity

    -It Occupies About 50% Small Area Compared With Other Ordinary Equipment

    -Adopt Guided Counter-Flow Sedimentation Inclined Tube Packing To Improve Surface Load, Sedimentation Effect and To Shorten Sedimentation Time

    -Stable and Excellent Outlet Water Quality

    -Strong Impact-Tolerance Capacity

    -Widely Application

    -Economical and Lower Investment Cost

    -High Automatic Control Degree

    -Easy Maintenance

    -Long Service Life

    Automatic Water Purification System Specification

    Model

    Capacity

    (M3/h)

    Dimension

    (L*W*H) m

    Pool NO.

    N.W.

    ( Ton )

    G.W.

    ( Ton )

    LWP-5

    5

    2.32*1.85*4.90

    1

    3.96

    8.30

    LWP-10

    10

    2.10*2.60*5.88

    1

    5.05

    14.20

    LWP-15

    15

    3.81*2.90*5.88

    1

    8.12

    22.63

    LWP-20

    20

    4.70*3.31*6.00

    1

    10.26

    28.90

    LWP-25

    25

    5.10*3.33*6.00

    1

    12.56

    36.68

    LWP-30

    30

    5.00*3.71*6.75

    1

    14.65

    44.50

    LWP-40

    40

    6.00*5.35*6.75

    1

    17.16

    57.20

    LWP-50

    50

    7.50*5.80*6.90

    1

    19.48

    65.50

    LWP-60

    60

    8.08*5.94*6.65

    1

    21.52

    79.50

    LWP-80

    80

    7.50*5.80*6.90

    2

    27.13

    105.00

    LWP-100

    100

    8.08*5.94*6.65

    2

    31.96

    129.00

    LWP-150

    150

    9.65*7.15*7.15

    2

    41.47

    191.00

    LWP-200

    200

    10.75*8.50*7.20

    2

    57.45

    255.00

    LWP-250

    250

    10.03*9.60*6.65

    2

    71.15

    320.00

    LWP-300

    300

    12.85*9.80*7.40

    2

    82.83

    380.00

    LWP-400

    400

    14.90*11.03*7.80

    2

    102.33

    502.00

    Comment

    -Common Water Inlet or Outlet Pressure:≥0.15 MPa or 0 Mpa

    -Common Inlet or Outlet Turbidity :≤3000NTU or ≤1NTU

    -Common Working Way: S1 Duty

    -Common Working Temperature: 0-35 ℃

     600 Integrated Purified Water System 4

    Working Principle

    The Fully Automatic Water Purifier Doses Flocculant Through The Stirring And Metering Dosing System, Enters The Raw Water Inlet Pipe, Mixes With The Raw Water Through The Tubular Mixer, And Then Enters The Inclined Tube Sedimentation Tank After Reacting Through The Folded Plate Reaction Tank. After Separation, The Clean Water Enters The Filter Tank From The Sump To Filter, And Then Obtains Qualified Drinking Water



    Application

    -Adapt for All River , Lake , Reservoir Source Water works Plant Device

    -All kinds of Water Station

    -As a perfect per-treatment of the high purify water, boiler Water& Beverage industry etc.

    - Used as improving Industrial Recycled Water Quality

    - Adopts in Mountain Spring ,Tunnel and Field Operations

    - Adopts in Gray Water Reuse.

    600 Integrated Purified Water System 2
