LCPT Series High Density Deep Cone Paste Thickener

 

LCPT Series High Density Deep Cone Paste Thickener

Payment Type: T/T

Supply Ability: 4 Sets Per 3 Months

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LCPT-24

Brand: Loren

Species: Mining Thickener

Applicable Industry: Energy &Amp; Mining, Food &Amp; Beverage Shops

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Plc, Bearing, Gearbox, Motor, Pump

Status: New

Motor Type: Ac Motor

Place Of Origin: China

Warranty Period: 2 Years

Key Function: Mining Slurry or Paste Concentration

Underflow Concentration: High & Stable

Customized: Design as per Real sites demand

Treated Capacity: 15-2600 m3

Taken Room: Smaller Than other Types

Safety: High with Overload Protection

Maintenance: Easy and Freely

Full Solution Consulstant: Available

OEM ODM Service: Available

Product Description

LCPT Series High Density Deep Cone Paste thickener

Definition of Deep Cone Mining Slurry Thickener

The Deep Cone Paste Thicker Is a Very Important Solid-Liquid Separation Equipment In Today's Concentrator

Composition of Central Drive Deep Cone Sludge Concentrator

It Is Mainly Composed Of Deep Cone, Feeding Device, Stirring Device, Control Box, Drug Delivery Device And Automatic Control System.

Solid Liquid Separator Slurry Clarifier Feature

- High & Stable Underflow Concentration

-Large Treated Capacity

-Small Footprint

-Module and Customized Design

-High Performance

- High Cost-Effective Ratio

-High Safety

-Easy Maintenance

-Energy Saving

-High Automation Degree Control

- OEM manufactured or SS Water-Touched Components Available

Structure &Working Principle

Under The Condition Of Adding Flocculant, The Flotation Tailing Are Sent Into The Lower Feeding Cylinder With a Conical Distribution Port. Most Of The Water In The Slime Water Flows To The Periphery In The Clarification Area Of The Thickener Cylinder, And a Small Part Forms a Small Eddy In The Floc Settlement Area. In The Conical Part Of The Machine Body, That Is, In The Compression Zone, The Sediment Is Compressed Under The Action Of Gravity And Released From The Bottom Outlet Or Pumped Out

Applicant

-Mining Coal Water Treatment

-Mining

-Mineral Processing

-Metallurgy

-Chemical Industry

-Alumina

-Environmental Protection

-Water Treatment

-Drainage Engineering

-Other Industries

Model Instruction and Specification

Model	Pool DN (M)	Capacity (M3)	Settle Area (M2)	Linear Speed（M/Min）	Drive Power (kw)	Underflow Concentration (%)
LCPT 10	10	10-86	78	8-12.5	18.5	50-75
LCPT 12	12	14-125	113	8-12.5	22	50-75
LCPT 14	14	19-169	154	8-12.5	37	50-75
LCPT 16	16	24-221	201	8-12.5	45	50-75
LCPT 18	18	30-280	254	8-12.5	55	50-75
LCPT 25	25	37-540	490	8-12.5	75	50-75
LCPT 30	30	85-775	706	8-12.5	90	50-75
LCPT 35	35	116-1060	962	8-12.5	110	50-75
LCPT 40	40	151-1382	1256	8-12.5	132	50-75
LCPT 45	45	190-1750	1590	8-12.5	160	50-75
